Coco Cola Bottle PET Injection Moulding Machine With Robot Interface

Brand Name : MINZEN

Model Number : MZ-K2-280

Certification : CE/ISO9001:2008

Place of Origin : China

MOQ : 1 set

Price : Price negotiation.

Payment Terms : L/C, T/T

Supply Ability : 100 sets per month.

Delivery Time : 30 work days.

Packaging Details : Wooden pellet Wooden case(optional)

Product : Coco Cola bottle PET Preform

Speed : High speed

Materia : PET

Robot : YES

Type : Servo system

Part : core pull and unscrew motor

Contact Now

Coco Cola bottle PET Preform Injection Molding Machine with robot interface

Standard configuration:

Adopt famous hydraulic components,

Yuken-Japan pump,Yuken-Japan direction valve,

Hydraulic motor for melting plastic using intermot italy-China

Back pressure valve Yuken Japan

Air switch from LG Korea

Breaker AC contactor, single phase breaker, three-phase breaker from Schneider france

T-slot makes the adjustment easier, compare with the screw adjustment, it has better adaptability and longer life-span

Optional function:

  1. nitrogen injection devices
  2. technological meter device for plasticizing speed indication
  3. prolonged nozzle
  4. hydraulic safety interlock
  5. core pull and unscrew motor
  6. robot interface
  7. special screw
  8. Be-clear at one glance for checking the chiller water speed and temp
  9. Auto-loader
  10. Hopper dryer
  11. Chiller
  12. Mixer
  13. Crusher
  14. Cooling tower

SPECIFICATIONS

SPECIFICATIONS
DESCRIPTION UNIT K2-280
INJECTION A B C
SHOT VOLUME CM3 700 792 930
SHOT WEIGHT G 636 720 845
(PS) OZ 22.2 25.2 29.5
SCREW DIAMETER MM 55 60 65
INJECTION PRESSURE MPA 211 177 151
SCREW L:D RATIO 22:1 20:1 18.5:1
SCREW STROKE MM 300
SCREW SPEED (STEPLESS) R/MIN 0~150
CLAMPING UNIT
CLAMPING FORCE KN 2800
OPENING STROKE MM 570
PLATEN SIZE MM*MM 870*850
SPACE BETWEEN TIE BARS MM*MM 610*590
MOLD THICKNESS (MIN-MAX) MM 220~620
MAX.DAYLIGHT MM 1190
HYDRAULIC EJECTION STROKE MM 160
HYDRAULIC EJECTION FORCE KN 77
POWER UNIT
HYDRAULIC SYSTEM PRESSURE MPA 17.5
PUMP MOTOR(V/S) KW 22/28.3
HEATING CAPACITY KW 18
NUMBER OF TEMP CONTROL ZONES 5+(NOZZLE )
GENERAL
DRY-CYCLE TIME SEC 5
OIL TANK CAPACITY L 380
MACHINE DIMENSIONS MXMXM 6.4*1.5*2.2
MACHINE WEIGHT KG 11000
